Mantis F6 SMART 3D Scanner
Regular price
$14,999.00
In stock
Outstanding Long Range Volumetric Scanner for Field Use
- IR light – enables work in any lighting conditions from complete darkness to daylight
- Ergonomic rubberized handgrip
- No scene preparation – geometry is deciphered by the encoding
- 2 layer modes of operation: static and dynamic
- Accessibility to hidden places
- User-friendly – professionals can operate the system after a short training
Best For
F6 SMART is suitable for a wide variety of uses and applications in:
- Automotive & Aftermarket Parts
- Reverse Engineering
- Architecture, Engineering, Construction
- Archaeology + Cultural Heritage
- Technical Room Scanning
- Education & Research
- Forensics
Rated as of the Top 10 Professional 3D Scanners from 3D Native
Features
Fast & Robust
F6 Smart built to operate in tough environment and under difficult light conditions
Powerful image projection
High Accuracy
Echo Software
A powerful scanning & 3D data editing tool, suitable for both professional and unprofessional users, both easy to use and high-performance software with strong denoise options and image projection mesh
Specs
| Working Range | 0.5-4m (20" to 14ft) |
| Max Accuracy (Max) | 500 micron, 0.5mm (0.019") |
| Depth Resolution (Max) | 1mm (0.039") |
| Field of View (Min) | 510 x 670mm (20 x 26") |
| Field of View (Max) | 4580 x 6070mm (15 x 20ft) |
| Ambient Light | 0-50000 Lux |
| Frame Rate | 8fps |
| Color Camera Resolution | 1.3MP |
| Data Acquisition Speed | 640000 points/sec |
| Eye Safety | Class 1 (safe) |
| Weight | 1kg (2.2lbs) |
| Working Temperature | -10 to 50°C (14 to 122°F) |
