Shining3D EinScan Rigil 3D Scanner
Sonderpreis
$4,999.00
Ausverkauft
Tri-Mode Handheld Laser & IR 3D Scanner with Built-In Computing
The Shining3D EinScan RIGIL is a handheld, tri-mode 3D scanner that combines blue laser scanning, IR VCSEL scanning, and on-board computing into a single portable device. It is designed for users who need flexibility across part sizes, surfaces, and environments without being tethered to a workstation.
RIGIL supports standalone scanning, wireless PC operation, or wired PC workflows, making it suitable for both shop-floor and field use.
Scanner Overview
- Handheld tri-mode 3D scanner
- Built-in compute and touchscreen
- Laser + IR hybrid light sources
- Supports standalone, wireless, and wired operation
- Designed for reverse engineering, inspection, and general-purpose 3D scanning
Typical Applications
- Reverse engineering
- General-purpose dimensional inspection
- Product development
- Field scanning and mobile workflows
- Scanning of mechanical parts and assemblies
Scan Modes & Light Sources
-
Laser HD Mode
- 19 + 19 crossed blue laser lines
- 7 parallel blue laser lines
- Intended for higher-detail geometry capture
-
IR Rapid Mode
- IR VCSEL structured light
- Optimized for faster scanning and larger objects
Workflow & Operating Modes
-
Standalone Mode
- Scan and process directly on the device
- No PC connection required
-
Wireless PC Mode
- Uses Wi-Fi 6 to connect to a PC
- Suitable for extended processing or larger datasets
-
Wired PC Mode
- USB-C connection for stable, high-bandwidth workflows
Specifications
- Accuracy & Resolution
- Volumetric accuracy (Laser HD): up to 0.04 + 0.06 mm/m
- Volumetric accuracy (IR Rapid): up to 0.1 + 0.3 mm/m
- Geometric resolution: up to 0.05 mm
- Scanning Performance
- Laser HD scanning speed: up to 4,400,000 points/s
- IR Rapid scanning speed: up to 1,600,000 points/s
- Laser working distance: 170 – 550 mm
- Recommended object size range: 160 – 1500 mm
- Alignment & Tracking
- Supported alignment methods include: Global markers, Markers, Features, Texture, Hybrid alignment
- Color & Texture Capture
- 5MP color camera
- Supports color texture acquisition where required
Software
- EXScan RIGIL software
- Supports scanning, alignment, meshing, and editing
- Includes tools such as:
- Global optimization
- Hole filling
- Scan rewind
- Measurement
- XYZ alignment
- Cutting planes
- Export and sharing
- Output Formats
- STL, OBJ, PLY, 3MF, ASC
On-Board Hardware (Built-In Compute)
- CPU: 8-core, 2.4 GHz
- RAM: 32 GB DDR5
- Storage: 32 GB eMMC + 1 TB SSD
- Display: 6.4″ 2K AMOLED touchscreen
- Batteries: 2 × 6000 mAh (replaceable)
- Charging: 60 W PD 3.0 fast charging
- Weight: 870 g (including batteries)
- Ingress rating: IP50
- Operating temperature: −10 °C to 40 °C
What’s Included
- EinScan RIGIL handheld scanner
- Batteries and charging accessories
- Calibration tools
- EXScan RIGIL software
- Carrying case
3DChimera Support
3DChimera provides:
- Scanner configuration guidance
- Application-specific workflow setup
- Training based on your parts and use cases
- Ongoing technical support
If you’re comparing Rigil to other Shining3D, Creaform, or Artec systems, we can help you determine whether its tri-mode flexibility and onboard compute align with your requirements.
